Animal Red Eye Frame
Brand | Animal |
---|---|
Colour | Red |
Wheel Size | 20-inch |
The Animal Red Eye frame is a long-anticipated work of art from the guys over at Animal Bikes. Hand crafted in the USA by @jcortsmetalworks from straight gauge 4130 Chromoly tubing for an extreme amount of strength that can withstand the abuse of even the most aggressive street riders.
Specification
- Frame Material: 4130 Chromoly
- Headset Type: Integrated (Campy)
- Bottom Bracket Type: Mid
- Brakemounts: None
- Seatpost Size: 25.4mm
- Seat Clamp: Non-Integrated
- Dropouts: 14mm
- Toptube Lengths: 20.5",20.75", 21", 21.25" or 21.5"
- Chainstay Length: 13-13.5"
- Headtube Angle: 75.75°
- Seattube Angle: 71°
- Standover Height: 9.25"
- Bottom Bracket Height: 11.8"
- Weight: 5Lbs 8oz
