S&M Big Jumper 26-Inch Frame



More Information
BrandS&M
Wheel Size26-inch

American manufacturers of frames, bars, stems, forks and more. All their steel and alloy parts are produced in-house and their frames hand-welded for ultimate quality control. Insane riders like Hoder and Hucker really put the frames to the test for complete end-user reassurance.

S&M Big Jumper 26-Inch Frame
S&M Big Jumper 26-Inch Frame S&M Big Jumper 26-Inch Frame

S&M believe 20-inch bikes are the original Dirt Jumpers and giving that moniker to 26-inch frames blows, but at the end of the day all that really matters is the ride. The 26-inch BJ is designed to go fast and high, soak up bumps and brake better than its smaller counterparts. And unlike a smaller-rigid bike, a 26-inch bike with a suspension fork and disc brake not only roasts transitions almost effortlessly, it leaves riders in better condition to have just as much fun the next day.

Features

  • Geometry based on 100 - 120mm Suspension or equivalent rigid fork
  • Headtube accepts 1.5" Tapered Steerer
  • Disc size is 160mm with 0mm IS to Post mount adaptor
  • Final stickers have not been decided on yet
  • Max Tyre 26-inch X 2.25" slammed (2.35" pulled back a bit)

Specification

  • Top Tube Lengths: 22-inch, 22.5", 23" or 23.5"
  • Rear End Length: 15.1" Slammed
  • Head Tube Angle: 69°
  • Standover Height: 10-inch
  • Bottom Bracket Height: 12.6" (.400" Drop)
  • Seat Tube Angle: 73°
  • Head Tube: 120mm Tall Integrated 42/52 Style
  • Bottom Bracket Style: 73mm Euro Bottom Bracket
  • Brake Mounts: 160mm Disc With 0mm IS To Post Mount Adaptor
  • Dropouts: 3/8" Slot 135mm Spacing W/Integrated Tensioners
  • Seat Post Size: 27.2mm Post - 30mm Clamp
  • Max Sprocket: 30 Tooth Standard Chain Line (32 With Additional Spacers)
  • Weight: 5.6Lbs (22-inch TT)
